1-27
ROCKY-6614 CPU Card
27

115.2Kbps transmission rate
2.11 Real Time Clock
256-byte battery backed CMOS RAM
2.12 System Monitoring
The ROCKY-6614 CPU board is capable of self-monitoring various aspects of its operating
status including:
 CPU, chipset, and battery voltage, +3.3V, +5V, and +12V
 RPM of cooling fans

CPU and board temperatures (by the corresponding embedded sensors)
2.13 Infrared Data Association (IrDA) Interface
The ROCKY-6614 CPU Board IrDA supports the following interfaces.
 Serial Infrared (SIR)
 Shift Keyed Infrared (ASKIR)
If you want to use the IrDA port, you have to configure SIR or ASKIR mode in the BIOS
under Super IO devices. Then the normal RS-232 COM 2 will be disabled.
2.14 USB Interfaces
The ROCKY-6614 CPU board has eight USB interfaces, six internal and two external. The
USB interfaces support USB 2.0.
2.15 BIOS
The ROCKY-6614 CPU Board uses a licensed copy of AMI BIOS. The features of the flash
BIOS used are listed below:
 SMIBIOS (DMI) compliant

Console redirection function support
 PXE (
P
re-Boot E
x
ecution
E
nvironment ) support
