1-26
CKY-6614 WSB- Card
26
IEI
®
Technology, Corp.
Supports PCI Message Signaled Interrupt (MSI)
2.9 Drive Interfaces
The ROCKY-6614 can support the following drive interfaces.
2 x SATA drives
4 x IDE devices
1 x FDD
2.9.1 SATA Drives
The ROCKY-6614 CPU Board supports the following SATA drives:
2 x first generation SATA drives with transfer rates up to 150MB/s
2.9.2 IDE HDD Interfaces
The ROCKY-6614 southbridge chipset IDE controller supports up to two HDDs with the
following specifications:
Supports PIO IDE transfers up to 16MB/s
Supports the following Ultra ATA devices:
o Ultra ATA/133, with data transfer rates up to 133MB/s
o
Ultra ATA/100
, with data transfer rates up to 100MB/s
2.9.3 Floppy Disk Drive (FDD)
The ROCKY-6614 CPU Board supports a single FDD. The following FDD formats are
compatible with the board.
5.25”: 360KB and 1.2MB
3.5”: 720KB, 1.44MB and 2.88MB
2.10 Serial Ports
The ROCKY-6614 CPU Board has two high-speed UART serial ports, configured as COM1
and COM2. The serial ports have the following specifications.
16C550 UART with 16-byte FIFO buffer
