ROCKY-6614 CPU Card
185
The audio configuration window in Figure D-9 allows you to test each connected speaker
to see if your 4-channel or 6-channel audio operates properly. If any speaker
malfunctions, you should then check the cabling or replace the malfunctioning parts.
Select each specific speaker to test its functionality. The speaker you select will be
highlighted and sound should be generated.
NOTE:
1. The test scenario that appears in the Speaker Test window
corresponds to the number of speakers you selected in the Sound
Effect
window.
2. You should select and deselect the Swap Center/Subwoofer Output
check box to see if these two devices properly work.
D.10 S/PDIF-In & S/PDIF-Out
These functions are currently not supported.
D.11 Connector Sensing
Figure D-10: Connector Sensing
