1-17
ROCKY-6614 CPU Card
17
USB Interfaces Eight USB 2.0 connectors supported
Serial Ports Two COM ports
Real Time Clock 256-byte battery backed CMOS RAM
Hardware Monitoring Cooling fans, temperature and system voltages
Power Management Supports Advanced Configuration and Power Interface
(ACPI) Specifications Revision 2.0
Infrared Support One Infrared Data Association (IrDA) interface
Ethernet Gigabit Ethernet (GbE)
BIOS AMI flash BIOS
Physical Dimensions 12.2cm x 34.1cm (width x length)
Operating Temperature Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Audio Interfaces One Audio Codec ’97 (AC’97) version 2.3 connector
Table 1-1: Technical Specifications
