1-95
ROCKY-6614 CPU Card
95

2E8/IRQ3
Serial Port 1 base address is 2F8/IRQ3
 Serial Port2 Mode [Normal]
Allows BIOS to select the mode for Serial Port 2

Normal
(Default) Serial Port 1 mode is normal

IrDA
Serial Port 1 mode is IrDA

ASK IR
Serial Port 1 mode is ASK IR

Parallel Port Address [Disabled]
This option allows BIOS to select the base addresses for the Parallel Port

Disabled
(Default) No base address is assigned to the Parallel Port

378
Parallel Port I/O port address is 378

278
Parallel Port I/O port address is 278

3BC
Parallel Port I/O port address is 3BC
 Parallel Port Mode [Normal]
The
Parallel Port Mode
selection allows you to select the mode the parallel port will
operate in.

Normal
(D
EFAULT) The normal parallel port mode is the standard mode
for parallel port operation.

Bi-directional
In the bi-directional mode the parallel port outputs
are 8-bits long. Inputs are accomplished by reading
4 of the 8 bits of the status register.

EPP
The parallel port will operate in the enhanced
parallel port mode (EPP). The EPP mode supports
