ROCKY-6614 CPU Card
163
A.1 BIOS Configuration Options
Below is a list of BIOS configuration options described in Chapter 5.

System Overview ...................................................................................................74
 Ratio CMOS Setting [18] .......................................................................................78
 Max CUPID Value Limit [Disabled].......................................................................78
 Execute Disable Bit [Enabled]..............................................................................78
 Hardware Prefetcher [Enabled] ............................................................................79

Adjacent Cache Line Prefetch [Enabled] ............................................................79

Hyper Threading Function [Disabled] .................................................................79

Auto Detect CPU and DRAM FREQU [Enabled]..................................................79

CPU Frequency Setting [200] ...............................................................................79

CPU/DRAM Frequency Ratio [1:1]........................................................................80
 DRAM Frequency [200*2 MHz]..............................................................................81
 Clock Spread Spectrum [Disabled]......................................................................81
 OnBoard PCI IDE Controller [Both]......................................................................82
 Onboard PCI IDE Mode [Legacy Mode]...............................................................83
 Onboard PCI S-ATA Controller.............................................................................83
 IDE Master and IDE Slave .....................................................................................83
 Hard Disk Write Protect [Disabled] ......................................................................84
 IDE Detect Time Out (Sec) [5]...............................................................................84
 ATA (PI) 80Pin Cable Detection [Host & Device]................................................85

IDE PIO Pre-Fetch Enable .....................................................................................85

Auto-Detected Drive Parameters..........................................................................86

Type [Auto] ....................................................................................................87

LBA/Large Mode [Auto].........................................................................................88

Block (Multi Sector Transfer) [Auto]....................................................................88
 PIO Mode [Auto] 88
 DMA Mode [Auto]...................................................................................................89
 S.M.A.R.T [Auto] 90
 32Bit Data Transfer [Enabled] ..............................................................................91
 On Board Floppy Controller [Enabled]................................................................93
