ROCKY-6614 CPU Card
87

LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a
method of addressing data on a disk drive is supported or not.
 Block Mode: Block mode boosts IDE drive performance by increasing
the amount of data transferred. Only 512 bytes of data can be transferred
per interrupt if block mode is not used. Block mode allows transfers of up
to 64 KB per interrupt.
 PIO Mode: Indicates the PIO mode of the installed device.
 Async DMA: Indicates the highest Asynchronous DMA Mode that is
supported.

Ultra DMA
: Indicates the highest Synchronous DMA Mode that is
supported.
 S.M.A.R.T.: Indicates whether or not the Self-Monitoring Analysis and
Reporting Technology protocol is supported.

Type [Auto]
The Type BIOS option determines the type of device that the AMIBIOS attempts to boot
from after the Power-On Self-Test (POST) has completed.

Not Installed
Selecting this value prevents the BIOS from searching
for an IDE disk drive on the specified channel.

Auto
(Default) This selection enables the BIOS to auto detect the IDE
disk drive type attached to the specified channel. This
setting should be used if an IDE hard disk drive is
attached to the specified channel.

CD/DVD
The CD/DVD option specifies that an IDE CD-ROM
drive is attached to the specified IDE channel. The
BIOS will not attempt to search for other types of IDE
disk drives on the specified channel.

ARMD
This option specifies an ATAPI Removable Media
Device. These include, but are not limited to:
 ZIP
