1-60
CKY-6614 WSB- Card
60
IEI
®
Technology, Corp.

1 x ROCKY-6614 single board computer
 1 x mini jumper pack
 1 x ATA 66/100 flat cable
 2 x SATA cables

1 x SATA power cable
 1 x Keyboard/ PS/2 mouse Y cable
 1 X RS-232 cable
 1 x ATX-12V cable

1 x USB cable
 1 x Utility CD
 1 x QIG
If one or more of these items are missing, please contact the reseller or vendor you
purchased the ROCKY-6614 CPU card from and do not proceed any further with the
installation.
4.3 ROCKY-6614 CPU Card Installation
WARNING!
1. Never run the CPU board without an appropriate heatsink and cooler
that can be ordered from IEI Technology or purchased separately.
2.
Be sure to use the CPU 12V power connector (CN10007) for the CPU
power.
WARNING!
Please note that the installation instructions described in this manual should
be carefully followed in order to avoid damage to the CPU Card components
and injury to you.
