1-96
CKY-6614 WSB- Card
96
IEI
®
Technology, Corp.
bi-directional communication between the system
and the parallel port device and the transmission
rates between the two are much faster than the
Normal mode.

ECP+EPP
The parallel port will operate in the extended
capabilities port (ECP) mode. The ECP mode
supports bi-directional communication between the
system and the parallel port device and the
transmission rates between the two are much faster
than the Normal mode
The parallel port will also be compatible with EPP
devices described above
 Parallel Port IRQ [IRQ7]
The Parallel Port IRQ selection allows you to set the parallel port interrupt address.

IRQ5
IRQ5 is assigned as the parallel port interrupt address

IRQ7
(D
EFAULT) IRQ7 is assigned as the parallel port interrupt address
5.3.5 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 8) allows you to change the
configuration for the H/W Health Function and shows you the operating temperature, fan
speeds and system voltages.
