IEI Technology ROCKY-6614 User Manual

1-16
CKY-6614 WSB- Card
16
IEI
®
Technology, Corp.

1 x Keyboard connector
The ROCKY-6614 CPU board has the following connectors on the board rear panel:
 1 x PS/2 connector
 1 x VGA connector

1 x LINE_OUT connector

1 x RJ-45 Ethernet connector
 2 x USB ports
The location of these connectors on the CPU Card can be seen in Figure 1-1. These
connectors are fully described in Chapter 3.
1.2.2 Technical Specifications
ROCKY-6614 CPU board technical specifications are listed in
Table 1-1
. Detailed
descriptions of each specification can be found in
Chapter 2 Detailed Specifications
.
SPECIFICATION
CPUs Supported
Intel
®
Pentium
®
4
Intel
®
Celeron
®
D
Chipsets Northbridge: SIS 661CX
Southbridge: SIS 964
I/O Controller SIS 964
Graphics Support
SiS Mirage™ Graphic Engine
Memory Two DDR memory modules (Max. 2GB)
PCI Bus Interface 33MHz, Revision 2.3
Serial ATA (SATA) Two SATA channels with 150MB/s transfer rates
HDD Interface Two IDE channels supports four Ultra ATA 100/66/33
devices
Floppy Disk Drive (FDD) Supports FDD
