ROCKY-6614 CPU Card
183
The equalizer in Figure D-7 allows users to change sound effect parameters. The default
screen shows equalized values. You may also select preset modes from the buttons
below. The configurable values include 10 bands of equalizer ranging from 100Hz to
16KHz. Use the scroll bar to fine-tune, and use the Load, Save, Delete, and Reset
buttons to edit your settings.
D.8 Speaker Configuration
Figure D-8: Speaker Configuration
In this functional window, you can configure your multi-channel speaker settings.
Select the audio configuration from the No. of Speakers section on the left by clicking on
one of the check circles.
The configurable options are:
 Headphone
 Channel mode for stereo speaker output

Channel mode for 4 speaker output
