E.2.3 Install SATA Drives
To implement the on-chip RAID function, two SATA drives must be connected to the
system. To do this use the SATA drive cables that came with your system to connect the
SATA drives.
E.2.4 Configure the SATA Controller in BIOS
To configure the RAID BIOS, follow the steps below:
Step 1: Turn on the motherboard and enter the BIOS setup utility. Do this by clicking
D
ELETE when the system boots up.
Step 2: Select the Advanced settings menus.
Step 3:
Select the
IDE Configuration
sub-menu.
Step 4: In the IDE Configuration sub-menu select the “Onboard PCI S-ATA
Controller” option (see Section 5.3.2 on BIOS IDE Configuration on page 81).
Step 5: Set the “Onboard PCI S-ATA Controller” option to the “Raid Mode” and hit
E
NTER
.
Step 6: Save your changes and exit the BIOS setup utility. To do this, hit the escape key
and select the Exit menu from the top menu bar in the BIOS utility setup.
Step 7: When you enter the Exit menu, select the “Save Changes and Exit” menu
option. Step 0:
E.2.5 Configure the RAID BIOS
The next step is to configure the BIOS RAID. To do this, follow the steps below.
Step 1: Restart your system. Wait for the POST to be complete.
Step 2: You will be prompted to press <CTRL> and <S> to enter the BIOS RAID Setup
Utility (see Figure E-4).
