ROCKY-6614 CPU Card
47
3.2.10 SATA Drive Connectors
CN Label: SATA1, SATA2
CN Type: 1x7 pin port
CN Location: See Figure 3-11
CN Pinouts: See Table 3-13
The SATA drive ports provide connectivity to SATA drives with a maximum data transfer
rate of 150MB/s.
PIN
DESCRIPTION PIN DESCRIPTION
1 GND 5 RX-
2 TX+ 6 RX+
3 TX- 7 GND
4 GND
Table 3-13: SATA Connector Pinouts
CAUTION!
Your SATA hard drives may come with both a 4P power connector and a SATA
power interface. Attach either the 4P connector or the included SATA power
cable to your SATA hard drives.
DO NOT
attach both the power connectors to
your SATA hard drives at the same time! Doing so will cause damage.
