1-66
CKY-6614 WSB- Card
66
IEI
®
Technology, Corp.
Figure 4-6: Securing the heatsink to the PCB board
Step 4: Use the screwdriver to tighten the four screws. Tighten each nut a few turns at a
time and do not over-tighten the screws.
Step 5: Connect the fan cable on the cooler fan to the CPU fan connector on the CPU
card. Make sure the fan cable does not touch any heat generating chips and fan
blades. Step 0:
4.3.3 DIMM Module Installation
4.3.3.1 Purchasing the Memory Module
WARNING!
The DDR2 architecture is not compatible with DDR1 modules. If your
system is installed with DDR1 modules, damage might occur and you
will not be able to boot up your system.
When you purchase your DIMM modules, the following considerations should be taken into
account:
