3.2.8 System Front Panel Connector
CN Label: F_PANEL1
CN Type: 2x7 pin header
CN Location: See Figure 3-9
CN Pinouts: See Table 3-11
The system panel connector connects to:
 the system chassis front panel LEDs

the chassis speaker
 the power switch
 the reset button.
PIN DESCRIPTION PIN DESCRIPTION
1 VCC5 2 VCC5
3 N/C
4
N/C
5 GND 6 N/C
7 Power Button 8 SPK
9 GND 10 N/C
11 VCC5 12 SYS_RST#
13 HD_LED (-) 14 GND
Table 3-11: System Panel Connector Pinouts
