IEI Technology ROCKY-6614 User Manual

1-94
CKY-6614 WSB- Card
94
IEI
®
Technology, Corp.
 Serial Port1 Address [3F8/IRQ4]
The Serial Port1 Address option allows BIOS to select the Serial Port 1 base address.

Disabled
No base address is assigned to Serial Port 1

3F8/IRQ4
(Default) Serial Port 1 I/O port address is 3F8 and the interrupt
address is IRQ4

3E8/IRQ4
Serial Port 1 I/O port address is 3E8 and the interrupt
address is IRQ4

2E8/IRQ3
Serial Port 1 I/O port address is 2E8 and the interrupt
address is IRQ3
 Serial Port2 Address [2F8/IRQ3]
The Serial Port2 Address option allows BIOS to select the Serial Port 2 base address.

Disabled
No base address is assigned to Serial Port 2

2F8/IRQ3
(Default) Serial Port 2 I/O port address is 3F8 and the interrupt
address is IRQ3

3E8/IRQ4
Serial Port 2 I/O port address is 3E8 and the interrupt
address is IRQ4

2E8/IRQ3
Serial Port 2 I/O port address is 2E8 and the interrupt
address is IRQ3
 Serial Port2 Address [2F8/IRQ3]
This option allows BIOS to select the base addresses for Serial Port 2

Disabled
No base address is assigned to Serial Port 2

2F8/IRQ3
(Default) Serial Port 1 base address is 2F8/IRQ3

3E8/IRQ4
Serial Port 1 base address is 2F8/IRQ3

IEI Technology ROCKY-6614 Specifications

General

Brand	IEI Technology
Model	ROCKY-6614
Category	Motherboard
Language	English
