IEI Technology ROCKY-6614 User Manual

1-34
CKY-6614 WSB- Card
34
IEI
®
Technology, Corp.
CD_IN1 4-pin header
MIC_IN1 4-pin header
KB1 Keyboard connector 5-pin header
Table 3-1: Peripheral Interface Connectors
3.1.3 Rear Panel Connectors
Table 3-2 lists the rear panel connectors on the ROCKY-6614 CPU card. Detailed
descriptions of these connectors can be found in Section 3.3 on page 51.
Label Connector Type
KB/MS_C1 Keyboard or Mouse connector PS/2
LAN_C1 Ethernet connector RJ-45
LAN_C2 Ethernet connector RJ-45
USB_C1 USB Connector USB Port
CN2 VGA Connector 15-pin VGA connector
Table 3-2: Peripheral Interface Connectors
3.1.4 Onboard Jumpers
Table 3-3 lists the onboard jumpers. Detailed descriptions of these jumpers can be found in
Section 3.4 on page 54.
Label Connector Type
JP2 Clear CMOS 3-pin header
Table 3-3: Onboard Jumpers
