Figure 3-3: IDE Connector Location
3.2.3 COM Ports
CN Label: COM1, COM2
CN Type: 2x5 pin headers
CN Location: See Figure 3-4
CN Pinouts: See Table 3-6
The ROCKY-6614 CPU board has two internal high-speed UART connectors accessed
through a 10-pin cable connector.
PIN DESCRIPTION PIN DESCRIPTION
1 DATA CARRIER DETECT (DCD) 6 DATA SET READY (DSR)
2 RECEIVE DATA (RXD) 7 REQUEST TO SEND (RTS)
