ROCKY-6614 CPU Card
45
Figure 3-9: System Panel Connector Location
3.2.9 IrDA Connector
CN Label: IR1
CN Type: 1x6 pin header
CN Location: See Figure 3-10
CN Pinouts: See Table 3-12
The integrated IrDA connector supports both the SIR and ASKIR infrared protocols.
