TECHNICAL SPECIFICATIONS
2
- 9 -
302.028
– The guide
C
sinks (fig. 5).
– The bar pusher
E
sinks; the bar-pusher axis is
positioned along the spindle axis (fig. 6).
– The bar pusher
E
is engaged in the carriage
D
(fig. 7).
– The bar pusher
E
causes the bar
B
to move on
according to the lathe impulses until it comes to an
end (fig. 8).
5
28.006 Ec.0
C
6
28.007 Ec.0
E
•
7
28_008_1
•
•
D
E
8
28_009_1
E
B
•
•
