USE AND OPERATION
6
- 41 -
302.028
– Press
to lower the bar lifting device again.
– Press
to lift the guide.
– Press
to prefeed the bar.
– Press
to move the carriage back to its end-
of-stroke position.
– Press
to lower the guide.
– Press
to lower the bar pusher.
– Press
to let the bar fore end come out of the
lathe collet by a few millimetres.
– Press
to select the automatic function. The
bar will be fed on according to the
selected program.
– Start the lathe cycle.
– The lathe collet closes, thus starting the machining.
From now on, bars will be fed automatically as long
as there are bars available or according the
selected program.
– If you wish to restock bars in the magazine during
machining, proceed as described in
paragraph 6.4.1.
