Key (Fig. 39):
A - Intake
C - Minimum slope 5%
S - Exhaust
In the C
(10)
and C
(12)
installations, the appliance ue exhaust must be tted with a Ø 80 ue gas non-return valve kit, consisting of the valve
itself with instructions, specication and relative sticker with additional safety information (Fig.34).
