Cygnus 2 Operating Manual
9.4.8 Query Sensor Parameter
Command = QS <Command ID> <Sensor Number>
Command ID = <Byte> See Table 9-7.
Sensor Number = <Byte> Sensor number 1 - 6
Response = <Integer> | <Float>
Type of response depends on command ID, see "Data Type" column in Table 9-7.
9.4.9 Update Sensor Parameter
Command: = US <Command ID> <Sensor Number> <Parameter Value>
Command ID = <Byte> See Table 9-7
Sensor Number = <Byte> Sensor number 1 - 6
Parameter Value = <Integer> | <Float> Type of value depends on command ID,
see Data Type column in Table 9-7.
Response = None (Just header and trailer)
Table 9-7 Sensor parameters
QS
&
US
Cmnd
ID
Name
(Units)
Range:
Low Limit/
High Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
1
(0x01)
(Sensor) Shutter
Out(put)
0/ 38/ 0 Integer 0 = not defined
Update not allowed if the Sensor is running. Not
accepted if output in use by other hardware
2
(0x02)
Sensor Type 0/ 4/ 0 Encode 0 = Single 1 = XtalTwo
2 = XtalSix 3 = Xtal12
4 = Generic
Update not allowed if
the Sensor is running.
3
(0x03)
(Sensor) Switch
Out(put)
0/ 38/ 0 Integer 0 = not defined
Gray font if Sensor Type =
Single
Update not allowed if
the Sensor is running.
Not accepted if output
in use by other
hardware.
4
(0x04)
Auto-Z 0/ 1/ 0 Encode 0 = No, 1 = Yes
