Cygnus 2 Operating Manual
9.4.28 Status General
Command = SG <Command ID><Option>
Command ID = <Byte> See "Description" in Table 9-12.
Option = <Byte> |< Integer > | <32 Bit Word> | <48 Bit Word>
Response = <Byte>… <Byte> | <Integer>…<Integer
Table 9-12 Status general commands
SG
Comm
and ID
Description Option
Number
of bytes
in the
response
Data Returned Notes
0
(0x00)
N/A
3
(0x03)
Output status 5 <Byte><Byte><Byte>
<Byte><Byte> Each bit
represents an output,
bit set means output
active.
MSB of first byte is
output 1.MSB of the
fifth byte is output 33.
4
(0x04)
Input status 4 <Byte><Byte><Byte>
<Byte> Each bit
represents an input. Bit
set means input active.
MSB of first byte is
input 1. MSB of the
fourth byte is input 25.
5
(0x05)
Logic statement
status
13 <Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte> Each bit
represents a logic
statement, bit set
means logic statement
is true.
MSB of first byte is logic
statement 1.MSB of the
thirteenth byte is logic
statement 97.
6
(0x06)
Status Messages 8 <Byte><Byte><Byte>
<Byte><Byte><Byte>
<Byte><Byte>
See encodes in section
13.1 on page 13-1. One
bit is set for each error.
Multiple bits may be
set.
