Cygnus 2 Operating Manual
9.4.5 Update General Parameter
Command = UG <Command ID> <Parameter Value>
Command ID = <Byte> See Table 9-5
Parameter Value = <Integer> | <Float> Type of value depends on command ID,
see "Data Type" column in Table 9-5.
Response = None (Just header and trailer)
General Parameters
Table 9-5 General parameters
QG
&
UG
Cmnd
ID
Name
(Units)
Range:
Low
Limit/
High
Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
9
(0x09)
Thickness Eq 1
0/
654321/
0
Integer Values are the Sources
whose thicknesses are
summed
No duplicate numbers
allowed
10
(0x0a)
Thickness Eq 2
11
(0x0b)
Thickness Eq 3
12
(0x0c)
Test 0/ 1/ 0 Encode 0 = Off
1 = On
13
(0x0d)
Time Compressed
(10x time
acceleration)
0/ 1/ 0 Encode 0 = No
1 = Yes
Gray font when Test = Off
14
(0x0e)
Advanced Test
(Crystal Fails
active)
0/ 1/ 0 Encode 0 = Off
1 = On
15
(0x0f)
Audio Feedback 0/ 1/ 0 Encode 0 = No
1 = Yes
16
(0x10)
LCD Dimmer Time
(Minutes)
0/ 99/ 0 Integer 0 = Always On
Non 0 = Minutes till off
17
(0x11)
Date Format 0/ 1/ 0 Encode 0 = mm/dd/yyyy
1 = dd/mm/yyyy
18
(0x12)
USB Datalog
Format
0/ 2/ 0 Encode 0 = Log Off 1 = Page
2 = Comma
