Inficon Cygnus 2 User Manual

9 - 13
Cygnus 2 Operating Manual
19
(0x13)
Datalog Xtal Info 0/ 1/ 0 Encode 0 = No
1 = Yes
20
(0x14)
Graph Scale 0/ 2/ 2 Encode 0 = Power 1 = ±10 Å/s
2 = ±20 Å/s
Update will change all
Material graphs (Materials
1 to 6) to the Graph Scale
choices 0 = Power, 1 =
±10 Å/s, or 2 = ±20 Å/s,
only.
21
(0x15)
Graph Scan Rate 0/ 3/ 0 Encode 0 = Auto 1 = Slow
2 = Med 3 = Fast
22
(0x16)
RS-232 Baud Rate 0/ 4/ 4 Encode 0 = 9600 1 = 19200
2 = 38400 3 = 57600
4 = 115200
Cannot update via
RS-232 communications
23
(0x17)
RS-232 Protocol 0/ 2/ 0 Encode 0 = Standard 2 = Dlog Page
1= Dlog Comma
Table 9-5 General parameters (continued)
QG
&
UG
Cmnd
ID
Name
(Units)
Range:
Low
Limit/
High
Limit/
Default
Data Type
Notes
Update Restrictions
and Display Notes
