Transpector MPH Operating Manual
2.2.2 Subnetworking
A subnetwork (or subnet) is a logically visible subdivision of an IP (Internet
Protocol) network. Splitting an IP network into multiple subnets is referred to as
subnetting. Subnetting sets the region of the IP address that will be used as a
Network Prefix for all IP addresses inside of a subnet. This is accomplished
through a subnet mask. Different types of subnet masks and their implications to
IP addresses are shown in Table 2-1.
As seen in Table 2-1, the subnet masks determine which octets of the IP address
are used as the network prefix.
In order for two network devices to communicate, they must be on the same
subnet. This means that they must not only be connected to the same internet
network, but must also have the same network prefix. If two devices have two
different network prefixes, this means that the two devices are on different subnets.
2.3 Transpector MPH IP Address
By default, Transpector MPH ships with an IP address of 192.168.1.100 with a
subnet mask of 255.255.0.0.
NOTE: When connecting Transpector MPH to an existing local network, there
must be a static IP address for each Transpector MPH being installed.
Contact the network administrator for IP address assignments.
2.3.1 Changing Transpector MPH IP Address
There are two different methods of changing the Transpector MPH IP address.
The first method utilizes the onboard Transpector Web UI to change the
IP address. Instructions for changing the IP address via Transpector Web UI can
be found in section 5.5.2.4 on page 5-23.
Alternatively, the IP address can be changed through a standalone.exe as
discussed next in section 2.3.1.1.
Table 2-1 Subnetting
Example 1 Example 2 Example 3
IP address 192.168.1.104 192.168.1.105 192.168.1.150
Subnet mask 255.255.255.0 255.255.0.0 255.255.255.192
Network prefix 192.168.1.0 192.168.0.0 192.168.1.128
Host Protocol 0.0.0.104 0.0.1.105 0.0.0.22
