Intel Arria 10 FPGA User Manual

Receive bus Receive bus FPGA Pin Number I/O Standard Description
B6 PCIE_EDGE_SMB
DAT
AU37 1.8 V SMB data
A1 PCIE_PRSNT1N — — Link with DIP switch
B17 PCIE_PRSNT2N_X
1
— — Link with DIP switch
B31 PCIE_PRSNT2N_X
4
— — Link with DIP switch
B48 PCIE_PRSNT2N_X
8
— — Link with DIP switch
B15 PCIE_RX_N0 AT39 High Speed
Differential I/O
Receive bus
B20 PCIE_RX_N1 AP39 High Speed
Differential I/O
Receive bus
B24 PCIE_RX_N2 AN41 High Speed
Differential I/O
Receive bus
B28 PCIE_RX_N3 AM39 High Speed
Differential I/O
Receive bus
B34 PCIE_RX_N4 AL41 High Speed
Differential I/O
Receive bus
B38 PCIE_RX_N5 AK39 High Speed
Differential I/O
Receive bus
B42 PCIE_RX_N6 AJ41 High Speed
Differential I/O
Receive bus
B46 PCIE_RX_N7 AH39 High Speed
Differential I/O
Receive bus
B14 PCIE_RX_P0 AT40 High Speed
Differential I/O
Receive bus
B19 PCIE_RX_P1 AP40 High Speed
Differential I/O
Receive bus
B23 PCIE_RX_P2 AN42 High Speed
Differential I/O
Receive bus
B27 PCIE_RX_P3 AM40 High Speed
Differential I/O
Receive bus
B33 PCIE_RX_P4 AL42 High Speed
Differential I/O
Receive bus
B37 PCIE_RX_P5 AK40 High Speed
Differential I/O
Receive bus
B41 PCIE_RX_P6 AJ42 High Speed
Differential I/O
Receive bus
B45 PCIE_RX_P7 AH40 High Speed
Differential I/O
Receive bus
A17 PCIE_TX_CN0 BB43 High Speed
Differential I/O
Transmit bus
A22 PCIE_TX_CN1 BA41 High Speed
Differential I/O
Transmit bus
A26 PCIE_TX_CN2 AY43 High Speed
Differential I/O
Transmit bus
continued...
6. Board Components
683526 | 2023.07.12
Send Feedback
Intel
®
Arria
®
10 FPGA Development Kit User Guide
77
