Intel Arria 10 FPGA User Manual

Board Reference Schematic Signal Name FPGA Pin
Number
I/O Standard
A3 FMCA_DP_M2C_N1 BA8 High Speed Differential
I/O
A7 FMCA_DP_M2C_N2 AY6 High Speed Differential
I/O
A11 FMCA_DP_M2C_N3 AV6 High Speed Differential
I/O
A15 FMCA_DP_M2C_N4 AT6 High Speed Differential
I/O
A19 FMCA_DP_M2C_N5 AP6 High Speed Differential
I/O
B17 FMCA_DP_M2C_N6 AN4 High Speed Differential
I/O
B13 FMCA_DP_M2C_N7 AM6 High Speed Differential
I/O
B9 FMCA_DP_M2C_N8 AL4 High Speed Differential
I/O
B5 FMCA_DP_M2C_N9 AK6 High Speed Differential
I/O
K5 FMCA_DP_M2C_N10 AJ4 High Speed Differential
I/O
K8 FMCA_DP_M2C_N11 AH6 High Speed Differential
I/O
K11 FMCA_DP_M2C_N12 AG4 High Speed Differential
I/O
K14 FMCA_DP_M2C_N13 AF6 High Speed Differential
I/O
K17 FMCA_DP_M2C_N14 AE4 High Speed Differential
I/O
K20 FMCA_DP_M2C_N15 AD6 High Speed Differential
I/O
C6 FMCA_DP_M2C_P0 AW7 High Speed Differential
I/O
A2 FMCA_DP_M2C_P1 BA7 High Speed Differential
I/O
A6 FMCA_DP_M2C_P2 AY5 High Speed Differential
I/O
A10 FMCA_DP_M2C_P3 AV5 High Speed Differential
I/O
A14 FMCA_DP_M2C_P4 AT5 High Speed Differential
I/O
A18 FMCA_DP_M2C_P5 AP5 High Speed Differential
I/O
B16 FMCA_DP_M2C_P6 AN3 High Speed Differential
I/O
B12 FMCA_DP_M2C_P7 AM5 High Speed Differential
I/O
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
88
