Board Reference Schematic Signal Name FPGA Pin

Number

I/O Standard

B8 FMCA_DP_M2C_P8 AL3 High Speed Differential

I/O

B4 FMCA_DP_M2C_P9 AK5 High Speed Differential

I/O

K4 FMCA_DP_M2C_P10 AJ3 High Speed Differential

I/O

K7 FMCA_DP_M2C_P11 AH5 High Speed Differential

I/O

K10 FMCA_DP_M2C_P12 AG3 High Speed Differential

I/O

K13 FMCA_DP_M2C_P13 AF5 High Speed Differential

I/O

K16 FMCA_DP_M2C_P14 AE3 High Speed Differential

I/O

K19 FMCA_DP_M2C_P15 AD5 High Speed Differential

I/O

C34 FMCA_GA0 BC16 1.8 V

D35 FMCA_GA1 BD16 1.8 V

D5 FMCA_GBTCLK_M2C_N0 AL7 LVDS

B21 FMCA_GBTCLK_M2C_N1 AJ7 LVDS

D4 FMCA_GBTCLK_M2C_P0 AL8 LVDS

B20 FMCA_GBTCLK_M2C_P1 AJ8 LVDS

D34 FMCA_JTAG_RST — —

D29 FMCA_JTAG_TCK — —

D30 FMCA_JTAG_TDI — —

D31 FMCA_JTAG_TDO — —

D33 FMCA_JTAG_TMS — —

G7 FMCA_LA_RX_CLK_N0 AU15 LVDS

D9 FMCA_LA_RX_CLK_N1 AR11 LVDS

G6 FMCA_LA_RX_CLK_P0 AV15 LVDS

D8 FMCA_LA_RX_CLK_P1 AT10 LVDS

G10 FMCA_LA_RX_N0 AR19 LVDS

C11 FMCA_LA_RX_N1 AW14 LVDS

G13 FMCA_LA_RX_N2 AN19 LVDS

C15 FMCA_LA_RX_N3 AT15 LVDS

G16 FMCA_LA_RX_N4 AP16 LVDS

C19 FMCA_LA_RX_N5 AV18 LVDS

G19 FMCA_LA_RX_N6 AU13 LVDS

C23 FMCA_LA_RX_N7 AV21 LVDS

continued...

6. Board Components

683526 | 2023.07.12

Send Feedback

Intel

Arria

10 FPGA Development Kit User Guide
