Intel Arria 10 FPGA User Manual

Board Reference Schematic Signal Name FPGA Pin
Number
I/O Standard
G22 FMCA_LA_RX_N8 AT8 LVDS
G25 FMCA_LA_RX_N9 AY12 LVDS
G28 FMCA_LA_RX_N10 AY14 LVDS
C27 FMCA_LA_RX_N11 AR21 LVDS
G31 FMCA_LA_RX_N12 BA14 LVDS
G34 FMCA_LA_RX_N13 BB18 LVDS
G37 FMCA_LA_RX_N14 AW17 LVDS
G9 FMCA_LA_RX_P0 AR20 LVDS
C10 FMCA_LA_RX_P1 AV14 LVDS
G12 FMCA_LA_RX_P2 AP18 LVDS
C14 FMCA_LA_RX_P3 AR15 LVDS
G15 FMCA_LA_RX_P4 AR16 LVDS
C18 FMCA_LA_RX_P5 AW18 LVDS
G18 FMCA_LA_RX_P6 AT13 LVDS
C22 FMCA_LA_RX_P7 AU21 LVDS
G21 FMCA_LA_RX_P8 AU8 LVDS
G24 FMCA_LA_RX_P9 AW12 LVDS
G27 FMCA_LA_RX_P10 AY15 LVDS
C26 FMCA_LA_RX_P11 AP21 LVDS
G30 FMCA_LA_RX_P12 BA15 LVDS
G33 FMCA_LA_RX_P13 BB17 LVDS
G36 FMCA_LA_RX_P14 AY17 LVDS
H8 FMCA_LA_TX_N0 AT22 LVDS
H11 FMCA_LA_TX_N1 AP19 LVDS
D12 FMCA_LA_TX_N2 AW11 LVDS
H14 FMCA_LA_TX_N3 AU17 LVDS
D15 FMCA_LA_TX_N4 AV13 LVDS
H17 FMCA_LA_TX_N5 AR14 LVDS
D18 FMCA_LA_TX_N6 AP17 LVDS
H20 FMCA_LA_TX_N7 AT9 LVDS
D21 FMCA_LA_TX_N8 AW19 LVDS
H23 FMCA_LA_TX_N9 AU12 LVDS
H26 FMCA_LA_TX_N10 AY11 LVDS
D24 FMCA_LA_TX_N11 AT18 LVDS
H29 FMCA_LA_TX_N12 BC15 LVDS
continued...
6. Board Components
683526 | 2023.07.12
Intel
®
Arria
®
10 FPGA Development Kit User Guide
Send Feedback
90
