USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 119
3.11.4. Switching OFF The UAS
Always switch OFF the UAS in the following order:
1. Camera (wait at least 10 seconds until it has stored all data and is fully powered
down).
2. Intel® Falcon™ 8+ UAV:
• Push and hold the power button.
The LED position lights will increase brightness.
The LED position lights will decrease brightness and simultaneously there will
be a short beep from the UAV.
• Let go of the button.
3. CTR:
• Push and hold the power button of the touchscreen tablet for approximately 3
seconds until “Slide to shut down your PC” is shown.
• Follow this instruction to fully power down the touchscreen tablet.
• Push and hold the POWER button of the CTR. The CTR will vibrate briefly.
• Let go of the button.
3.12. WARNINGS
The Intel® Falcon™ 8+ UAS displays all warnings which might occur, in the status line at
the bottom of the Status Display and in the notification area at the top of the
touchscreen tablet. When there is no warning to display, the status line shows OK. On
the tablet SYSTEM OK is shown in the notification area.
A small loudspeaker is connected to a headphone port (mini jack), which is located on
the upper left-hand side of the CTR (“Intel® Cockpit Controller (CTR) Overview” on
page 24). It is possible to connect headphones there, which might be helpful under
noisy conditions.
Table 3.6: Possible Warnings
SHOWN TEXT REASON SIGNALS
Status Display: BATTERY
WEAK!
Tablet: Falcon battery
weak. Land soon!
The battery of the UAV
is weak.
Vibration on the CTR
Acoustic: Battery weak.
Land soon! repeated every
20 seconds
Visual: The voltage display
of the UAV on the Status
Display flashes.
