USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 125
3.12.3. Data Link Warnings
The following data link warnings may occur in the status line at the bottom of the
Status Display.
Table 3.9: Diversity Data Link Warnings
REGARDING SIGNALS EXPLANATION
Diversity data
link signal
Acoustic: Link weak
Tactile: Vibration on CTR
Visual:
The Intel® Falcon™ 8+ UAV has two
fully independent data link connec-
tions. In case one link is disturbed, the
LINK WEAK message is shown. Nev-
ertheless, the system can still be fully
controlled via the second indepen-
dent link, on a different channel in the
2.4 GHz band.
Check if the antenna panel of the CTR
is completely unfolded and reduce
the distance to the UAV until the sig-
nal strengthens.
In case of the LINK WEAK message
pushing the arrow RIGHT button
three times opens the shown screen
with details about the signal strength
of both data link connections.
Acoustic: Link lost
Tactile: Vibration on Cock-
pit Visual:
The UAV has flown out of range and
there is no data link connection
between UAV and CTR anymore. In
this case the preselected Link Loss
Procedure is automatically activated.
