USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 41
2.5.4. Inspection Payload
The Inspection Payload consists of two cameras: Panasonic RGB camera and infrared
(IR) camera FLIR TAU 2 640.
• Weight of the complete payload including gimbal: 550 g
• Approximate maximum flight time: approximately 18 minutes
After pushing the Fn button (number (1)
above) by default the following parame-
ters can be accessed:
Top row:
Drive Mode / Flash Mode / Flash Comp. /
Focus Mode / Focus Area / Exposure
Comp.
Bottom row:
ISO / Metering Mode / White Balance /
DRO/Auto HDR / Creative Style / Shoot
Mode
The camera menu can be accessed by
pushing the MENU button (number (2)
above). On the first page of the menu, the
Image Size and Quality can be set. Refer
to the camera manual for further details.
Figure 2.17: Camera Settings By Camera Sony Alpha 7R (Continued)
