USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 51
Menu Option 4, Overall Capacity
Menu option 4 shows the current possible amount of charge the battery may hold
when fully charged (as a percentage) compared to the factory battery capacity.
Menu Option 5, Battery Status
Menu option 5 shows the difference (as a percentage) between the highest measured
cell voltage and the lowest measured cell voltage, measured at the same time.
The BMS tries to balance the charging status of all 4 battery cells to the same level. By
measuring the difference between the highest cell voltage and the lowest cell voltage,
the actual battery status is determined. This status can be shown by activating menu 5.
Table 2.5: Charging Cycles
THE LEDS SHOW THE TOTAL NUMBER OF CHARGING CYCLES OF THE BATTERY
FROM RIGHT TO LEFT BEGINNING WITH LED 5 (GREEN) = 20, THIS NUMBER
SHOULD BE MULTIPLIED BY 10
STATUS OF LED NO. 1 2 3 4 5
(EXAMPLES)
CHARGING STATE
OFF OFF OFF OFF ON 20 = 1 X 10 ≙ 0 - 10
OFF OFF OFF ON OFF 21 = 2 X 10 ≙ 11 - 20
OFF OFF OFF ON ON 20 + 21 = 3 X 10 ≙ 21 - 30
OFF OFF ON OFF ON 20 + 22 = 5 X 10 ≙ 41 - 50
OFF ON ON ON ON 20 + 21 + 22 + 23 = 15 X 10 ≙ 141 - 150
Table 2.6: Battery Capacity
THE LEDS SHOW THE CURRENT POSSIBLE BATTERY CAPACITY AS PERCENTAGE
COMPARED TO THE FACTORY BATTERY CAPACITY
STATUS OF LED NO. 1 2 3 4 5 REMAINING CAPACITY
ON OFF OFF OFF OFF 51% - 60%
ON ON OFF OFF OFF 61% - 70%
ON ON ON OFF OFF 71% - 80%
ON ON ON ON OFF 81% - 90%
ON ON ON ON ON > 90%
