USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 129
3.12.7. AscTec Trinity Control Unit System Warnings
Whenever there is a system warning, (shown as SYSTEM ERROR in the notification
area on the touchscreen tablet), the bottom line of the Status Display will show <-
Check Msg
.
The table below shows all possible warnings, their meaning, and possibilities for
resolving them. All messages always have one of the prefixes N1U / N1C / N2U / N2C,
meaning:
• N1 = Navigational processor 1
• N2 = Navigational processor 2
• U = message concerning the user - might be application critical but not flight
critical
• C = message concerning the core - flight critical!
Figure 3.22: System Warnings
If <- Check Msg is shown in the status line there is
no acoustic warning. In this case push the arrow LEFT
button five times (when starting on the Main Screen of
the Status Display).
The Error Message Screen (shown on the left) is
opened, and the details are presented.
Table 3.13: AscTec Trinity Control Unit System Warnings
CATEGORY WARNING/
ERROR
MEANING CONSEQUENCE POSSIBLE
FIXES
License chip
UUID chip
mal-
function!
UUID chip not
functional (can-
not be installed /
not programmed
/ defective)
Serial Number is
31000 (default),
no flags can be
stored
Contact sup-
port.
