USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 18
2. DESCRIPTION OF THE SYSTEM
In this chapter, you find a description of the whole system and its components:
• The Intel® Falcon™ 8+ UAV
• The Intel® Cockpit Controller (CTR)
• Payloads/Cameras
• The Intel® Powerpack Batteries
2.1. THE INTEL® FALCON™ 8+ UAV
The following section describes the single parts of the Intel® Falcon™ 8+ UAV.
Figure 2.1: The Intel® Falcon™ 8+ UAV Components
The Intel® Falcon™ 8+ UAV consists of
several components:
(1) Actively stabilized camera mount
(gimbal) with camera
(2) Motor rails
(3) Central unit
(4) Carbon cross
The Intel® Falcon™ 8+ UAV bottom view:
(1) Actively stabilized camera mount with
camera
(2) Motor rails
(3) Center cross piece with LEDs
(4) Carbon cross
(5) Landing feet
For orientation reasons, the UAV has
three LED position lights:
• white at the bottom
• green on the right side
• red on the left side
1
2
2
3
4
4
4
4
1
2
2
3
4
4
5
5
