USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 40
2.5.3.4. Camera Settings
The following section describes the most important settings of the camera when used
with the Intel® Falcon™ 8+ UAV.
Adjust
Horizon
Occasionally the neutral position of the Gimbal's Servo Motors
might need to be re-adjusted. Use this command to adjust the
horizon (roll angle) while flying. If the system is still on the
ground and the motors are not running this can also be done in
both axes (roll and tilt) with the control sticks. see “Adjusting The
Camera Horizon” on page 36.
Roll Comp.
On/Off
Default = ON.
When Roll Comp. = Off the gimbal will no longer compensate
roll movements of the Intel® Falcon™ 8+ UAV.
This can be useful when doing dynamic video flights.
Figure 2.17: Camera Settings By Camera Sony Alpha 7R
The most important settings can be
quickly accessed via the buttons:
(1) Fn: see below
(2) MENU: see below
(3) C2: provides quick access to the
Focus Mode
(4) WB: provides quick access to White
Balance.
ISO can be quickly accessed by turning
the control wheel in the back of the cam-
era.
Table 2.2: Sony Alpha 7R Camera Control By Status Display (Continued)
THE FOLLOWING OPTIONS ARE AVAILABLE FOR THE SONY ALPHA 7R.
