USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 139
4.1.1. Status Display Menu Structure
For further information in terms of the Status Display see “The Status Display” on
page 27.
Table 4.1: Status Display Menu Structure
After switch-
ing on the CTR
the first screen
you see on the
Status Display
is the
Welcome
Screen.
After some
seconds, the
screen
changes to the
Start Screen.
If the UAV is
switched on
and there is no
connection
established to
the CTR, you
should push
ENT. The fol-
lowing screen
appears:
For entering
the serial num-
ber see “Estab-
lishing A
Connection
Between The
CTR And The
UAV” on
page 172.
By pushing the
RIGHT arrow
button the lati-
tude and lon-
gitude of the
last known
position of the
UAV are
shown:
Pushing ESC
on the
screen, with
last known
position,
brings you
back to the
Main
Screen.
