USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 19
The Intel® Falcon™ 8+ UAV bottom view,
Carbon Cross with center cross piece,
antenna arrangement:
The data link antennas (2.4 GHz) as well
as the video link antennas (5.8 GHz) are
integrated into the landing feet.
They are diagonally arranged as shown
in the image to the left.
Figure 2.1: The Intel® Falcon™ 8+ UAV Components (Continued)
Data
Data
Video
Video
