USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 181
2 INDEPENDENT (DIVERSITY)
COMMAND AND CONTROL LINKS
2.4 GHz adaptive FHSS link with 100
mW
(FCC compliant version)
DIGITAL VIDEO LINK Low latency digital link. 5.1 Ghz to 5.8
GHz with
24 dBM / 250 mW (FCC compliant ver-
sion).
Resolution depending on payload up to
1080 p Full HD
INTEL® COCKPIT CONTROLLER (CTR)
DIMENSION (W X L X H) 320 x 380 x 135 mm (12.60 x 14.96 x
5.31 in)
WEIGHT 2.7 kg (5.95 lbs) (w/o battery)
3.1 kg (6.83 lbs) (with battery)
POWER SUPPLY 1 x Intel® Powerpack Battery
OPERATING TIME* 2 h
OPERATING TEMPERATURE -5 °C to 45 °C (23 °F to 113 °F)
SHORT TERM STORAGE
TEMPERATURE
(UP TO ONE MONTH)
-5 °C to 40 °C (23 °F to 104 °F)
LONG TERM STORAGE TEMPERATURE
(BEYOND ONE MONTH)
-5 °C to 25 °C (23 °F to 77 °F)
TOUCHSCREEN Size 8.3'', resolution 1980 x 1200 px
CONNECTIONS 4 x USB, 1 x HDMI
INTEL® POWERPACK BATTERY
TYPE Lithium Polymer (LiPo) 4S
CAPACITY 4000 mAh
VOLTAGE (NOMINAL) 14.8 V
ENERGY 59.2 Wh
OPERATING TEMPERATURE*** -5 °C to 40 °C (23 °F to 104 °F)
Table 7.1: Technical Data (Continued)
