USER MANUAL
INTEL® FALCON™ 8+ UAS
© 2017 Intel Corporation. All rights reserved 59
Intel® Cockpit Controller (CTR)
Case
This case contains:
CTR with mounted sun shield
1. When transporting the CTR in the
case, the sunshield must be arranged
like shown to provide extra
protection of the touchscreen tablet
against scratches during
transportation.
2. Additional space
3. Additional space e.g. for an extra
power supply
Included in the case but not shown:
Shoulder harness is underneath the sun
shield protected touchscreen tablet.
Payload Case
The payload of the Intel® Falcon™ 8+ UAS
must be placed as shown on this image.
Make sure that it is placed conveniently
inside of the foam bolster. The foam bol-
ster cover (not shown) on top of the pay-
load should be used to secure the
payload when it is transported mounted
on the UAV in the Intel® Falcon™ 8+ UAV
case.
Figure 2.26: Packing Instructions for the Intel® Falcon™ 8+ UAS Cases (Continued)
To Next Page
