Intermec PC4

Chapter 4 — ESim Commands
104 ESim for the PC4 and PF8 Printers Programmer’s Reference Manual
p
1
= 12.5 mm (100 dots)
p
2
= 3.0 mm (24 dots)
p
3
= 3.0 mm (24 dots)
Example 2: Butterfly Label
The Q command would be:
Q100,24+24

Q - Set Form Length (Black Mark)
Purpose: Use this command to switch from label gap sensor to the black mark
sensor, and to specify the location and height of the black marks on
the back of the media.
Syntax:
Qp
1
,Bp
2
[±p
3
]
.
p
p
p
PRINT
DIRECTION
1
2
3
Q Command Parameter Descriptions
Parameter Description
p
1
Distance between black marks measured in
dots.
B Disables label gap sensor and enables the
black mark sensor.
p
2
Height of black mark measured in dots.
±p
3
Optional offset length measured in dots.
