- Bora/Spectra XTR
116
8.1.2 Fixed seat unit
Requirements:
• open-ended spanner, 13 mm
• 13 mm jaw spanner
• Loosen the bolt (1) with a 13 mm socket
spanner. Hold the nut using a 13 mm jaw
spanner to prevent rotation (not visible in
figure).
• Remove the bolt together with the flat washer
(3), the safety belt (4) and the spacer (2).
• Replace the safety belt (1).
• Refit the parts in the reverse order.
