Invacare Bora - Flex2 Seat

Invacare
®
- Bora/Spectra XTR
SERVICE MANUAL
129
9.2.2 Flex2 seat
Requirements:
• 4 mm Allen wrench
• 5 mm Allen wrench
• 13 mm open-ended wrench
• Flat screwdriver
• Smal hammer
WARNING: Danger of crushing!
The seat is very heavy. Danger of injury to hands and feet!
• Pay attention to the hand and feet.
• Use proper lifting techniques.
The illustration shows the Flex2 seat from above
without seat covering.
• Loosen the fixation screws at the
appropriate positions (2).
• Slide the Flex2 seat forward or rearward
until the fixation screws can be inserted into
the corresponding variation holes:
1 – Rear
2 – Middle
3 – Front
• Replace the fixation screws and tighten.
• Re-install all seat components.
• Check all functions during a test-drive.
