SERVICE MANUAL
Invacare
®
- Bora/Spectra XTR
86
7.14.2 Repairing a flat tyre (wheel size 280/250-4)
Requirements:
• Allen key 6m
• jaw spanner 13 mm
• 2 x small ring spanners or flat screwdrivers (for pulling off tyres)
• Repair kit for tyre repair or a new inner tube.
• Talcum powder
Removing the wheel:
• Block up the vehicle (place wooden blocks under
frame).
• Undo the bolt (1) and remove it using the Allen key
on one side and the jaw spanner on the other (as a
counter).
• Pull the wheel out of the fork.
Note
Re-assembly is done in reverse order. Ensure that the tyre is replaced on the same side and in
the same travel direction as it was previously mounted.
