Invacare Bora - Replacing Seat Belts (Modulite Seat); Installation on the Backrest Mounting Bracket (Simple Backrest)

Invacare
®
- Bora/Spectra XTR
SERVICE MANUAL
117
8.2 Replacing seat belts (Modulite seat)
8.2.1 Installation on the backrest mounting bracket (simple backrest)
Requirements:
• Socket spanner,13 mm
• 5 mm Allen key
• The seat belts are attached via the drill hole (1) at the top right.
• The installation of seat belts is described in chapter 8.1.1.
