Invacare Bora - Replacing the Front Bulb Holder (LED Lighting Unit)

SERVICE MANUAL
Invacare
®
- Bora/Spectra XTR
76
7.11.2 Replacing the front bulb holder (LED lighting unit)
Requirements:
• Jaw spanner 7 mm
• Allen key 3 mm
• TX25 torx screwdriver
• oblique pliers
• cable binder
• Loosen the nut (2) with a 7 mm jaw spanner
and a 3 mm Allen key and remove.
• Remove the front headlight (1) from the lamp
holder (3) and place it carefully to the side.
• Undo and remove the two screws (4) with a
TX25 torx screwdriver.
• Replace the lamp holder (3).
• Reassembly takes place in the reverse order.
• To complete, check all vehicle functions.
