Invacare Bora - Removing the Battery Cases

Invacare
®
- Bora/Spectra XTR
SERVICE MANUAL
63
7.7.1 Removing the battery cases
ATTENTION: Danger of crushing!
The batteries are extremely heavy. This results in injury hazards to your hands.
• Bear in mind that the batteries are sometimes very heavy!
• Please handle the batteries with care.
Note
A spare fuse is located behind the Invacare logo on the rear battery.
• Pull the rear battery case backwards using
the belt. The locking device opens
automatically when doing so.
• Pull the battery cases out using the side
handles.
