SERVICE MANUAL
Invacare
®
- Bora/Spectra XTR
38
7 Repair work
7.1 General warning information about fitting work
CAUTION!
Danger of damage to vehicle! Collisions can be caused if the adjusting washers are
removed during fitting work to the drive wheels!
Adjusting washers are often fitted between the drive shaft and the wheel hub to even out
tolerances. If these adjusting washers are removed and not replaced again, collisions can be
caused!
• Always replace the adjusting washers exactly as they were before you started dismantling!
CAUTION!
Danger of injury and damage to property, if the maximum speed reduction on a
wheelchair with a lifter does not function correctly!
The wheelchair’s control unit must reduce the maximum possible speed as soon as the lifter is
raised.
• Test the maximum speed reduction for correct function after any maintenance work or
modifications to the wheelchair.
7.2 Replacing drive components
ATTENTION: Danger of crushing!
The mobility and the seat ar
e very heavy. Danger of injury hazard to hands and feet caused
by uncontrolled tilting oder other movement!
• Use proper lifting techniques.
• Remove the seat and place the mobility device upside down so that the wheels are facing
upwards! This guarantees mobility device stability during repair work!
• Please see the following work steps for further important information.
ATTENTION!
Fire and burns hazard if battery terminal is bypassed!
• Please take great care to ensure that the battery terminals are never short-circuited with tools
or mechanical mobility device parts!
• Ensure that the battery terminal caps have been replaced if you are not working on the battery
terminals.
Requirements:
• small flat screwdriver
• Torx TX40 spanner
• Allen key 5 mm
• wooden block (approx.12 x 12x 30 cm for propping up vehicle)
• hairdryer
• high-strength screw blocker system, e.g. Loctite 270
• oblique pliers
